50 years in Representing Quality Manufacturers

Hand Tools

DEPRAG provides a full range of manual screwdrivers, screwfeeders, and automated screwdriving components and packages.

DEPRAG air and electric screwdrivers offer exact control of tightening screws with plus/minus 3% torque accurate clutch.

DEPRAG Minimat pneumatic tools:

  • Guaranteed 3% torque precision air tools and many quality control functions
  • Wide variety of torque ranges from 3 in./oz. to 50 ft. lbs.
  • Lightweight, yet durable for harsh industrial environments
  • Guaranteed 3% torque precision air tools and many quality control functions
  • Electric models with torque and angle monitoring and control
  • Ergonomic design grip. Lightweight, non-slip
  • Straight, pistol grip, angle head models
  • Special application drivers for screw counting and process control
  • Hand tool accessories: Stands, balancers, screw presenters

DEPRAG Minimat-E electric tools:

  • Fully programmable electric servo motors and PC-based controller with integrated display and keyboard
  • Ethernet IP, web browser (no special software), multilevel password protection
  • Available in straight inline and pistol style
  • Programmable torque and angle precision control
  • Controller includes standard screwdriving programs for torque and angle
  • Controller includes menu of selectable assembly steps to quickly build custom programs
Application
  • Automotive parts
  • Plastic car interiors
  • Electrical panels
  • Electronic circuit boards
  • Electrical distribution assemblies
  • Precision assemblies with torque control

Screwfeeders

DEPRAG screwfeeders provide operator convenience and productivity with automatic presentation of the fastener to the screwdriver

  • Reduce cycle time
  • DEPRAG fastener feeders are of two types: vibratory and non-vibratory sword type.
  • DEPRAG feeders can also be tooled to feed rivets, nuts, bolts and other fasteners.
  • Screwfeeders are delivered as complete, plug-and-play units ready to function with DEPRAG screwdrivers
  • Eliminate gripping, lifting, starting, and positioning of screws by hand
  • Improve quality by eliminating dropped or loose screws in final assemblies
  • Large feeding capacity with bulk hopper option
  • One feeder can support two manual screwdrivers
  • Sensor and LED to indicate fastener has been sent to driver
  • Low noise level of 70 dB(A) with integral enclosure
  • Fifth generation product: Experience and expertise assure product quality and reliability. Durable and reliable design and construction
Application
  • Automotive parts such as alternators, radios
  • Plastic car interiors such as dash and door panels, sun visors, steering wheels
  • Electrical panels
  • Electronic circuit board installation
  • Electrical distribution assemblies
  • Home appliances, washer, dryers, ovens, refrigerators, microwaves, mixers
  • Lawn and garden tools such as lawn mowers, snow blowers, trimmers, edgers

Spindle Units

DEPRAG screwdriver spindles are designed for automated integration with custom designed assembly stations and machines.

Common pneumatic and electric screwdriver spindle features:

  • Screwfeeder options with integrated screwdriver function module with spindles
  • Integrate with DEPRAG screwfeeder and multi-spindle manifold screw delivery
  • Easy to integrate into automation assembly machines
  • Available as straight spindles and angle nut runners
  • +/- 3% torque accuracy
  • DEPRAG Screwdriver Function Modules (SFM). Spindle mount modules for ease of integration onto assembly machines or end-of-arm robotic applications.

Pneumatic spindle features:

  • Unique air motor clutch release/shut off function assures precision in screw driving process
  • Sensor driver with automatic shut-off and with integrated transducer for angle and torque measurement
  • Control driversprovide automatic shut-off with integrated function control

Electric spindle features:

  • Electric spindles with 1% or better torque and angle accuracy
  • Individually adjust electric driver torque, speed, standby, and turn direction for each assembly requirement
  • EC “electronically computed” brushless electric servo driversprovide high torque at low speeds with minimum wear
  • Fully programmable torque, angle, rotation with optional AST 40 controller

Additional Features:

  • Eliminate stripped, missing, and mixed screws
  • Control angle with electric drivers
  • Fully programmable torque, angle, rotation with optional AST 40 controller
  • Unique air motor clutch release/shut off function assures precision in screw placement
  • Individually adjust electric driver torque, speed, standby, and turn direction for each assembly requirement
  • For use with DEPRAG standard spindle mounting fixture or provide your own slide for mounting
Application
  • Automotive parts such as alternators, radios
  • Plastic car interiors such as dash and door panels, sun visors, steering wheels
  • Electrical panels
  • Electronic circuit board installation
  • Electrical distribution assemblies
  • Precision assemblies with torque and/or angle control
  • Robotic screwdriving assemblies
  • Air drivers without lubrication for use in clean-rooms
  • Home appliances, washer, dryers, ovens, refrigerators, microwaves, mixers
  • Lawn and garden tools such as lawn mowers, snow blowers, trimmers

Custom Design

DEPRAG designs and builds modules and stations incorporating DEPRAG screwdrivers and screwfeeders.

  • Complete, turnkey screwdriving stations and modules
  • Standard components already designed and field-tested
  • Consider optional ancillary assembly, labeling and testing

DEPRAG offers basic untooled DCAM XY and optional Z chassis on which DEPRAG drivers and screwfeeders can be employed.
